8x16mm AC220V LED Neon Flex
- LED Neon
- AC220V · 9W/M · 700lm
- Profile size confirmed by drawing · 50M supply length
- 3000K / 4000K / 6500K / BLUE
- Confirm for selected construction · standard MOQ 3,000m
Application Scenarios
This LED strip is widely used in the following commercial and project environments.
Technical Specifications
Complete technical parameters for engineering reference and project specification.
| Model | neon light 8*16mm |
| LED Technology | LED Neon |
| Input Voltage | AC220V |
| Power Consumption | 9W/M |
| Lumen Output | 700lm |
| LED Density | Confirm on quotation |
| PCB / Profile Width | See approved drawing |
| Color Options | 3000K / 4000K / 6500K / BLUE |
| Color Rendering Index | Not specified |
| IP Rating | Confirm for selected construction |
| Supply / Reel Length | 50M |
| Warranty Listed | 2 years |
Product Features & Advantages
Detailed technical advantages and real-world benefits for your project.
Product overview
8x16mm AC220V LED Neon Flex with AC220V, 9W/M, 700lm, 3000K / 4000K / 6500K / BLUE, 50M, 2 years. Available supply length: 50M. Technical configuration and final specifications are confirmed for each order.
Confirmed configuration
- AC220V
- 50M supply length
The available color configuration is 3000K / 4000K / 6500K / BLUE. The current supply length is 50M. The listed warranty is 2 years.
Buyer specification checklist
Before ordering, confirm voltage, powered run length, driver or rectifier, controller protocol, cable and connector, color or CCT, IP construction, mounting profile, reel length, packaging, quantity, destination and measurable acceptance criteria.
Specification source
This page uses the September 2026 product sheet and intentionally excludes its internal price columns. Technical values should be reconfirmed on the formal quotation and approved sample.
OEM & Customization Options
Full product customization for brand owners, distributors, and project contractors.
Manufacturing & Order Planning
Production capability and model-specific commercial planning for B2B orders.
Standard minimum order quantity; custom requirements are confirmed on quotation.
Automated placement capacity for standard and customized models.
Manufacturing, engineering and quality-control support.
Commercial support for domestic and international customers.
Frequently Asked Questions
Common questions from importers, wholesalers, and project contractors about this product.
This is an AC220V model rated at 9W/M. Use only the matching rectifier or plug set, connector and protection method approved for this construction. Confirm the cutting unit, maximum powered length and local mains-installation rules before ordering.
No. 50M is the available supply or reel length. Maximum powered length depends on the exact model, voltage, watts per meter, feed direction, cable resistance, connectors and the accepted voltage drop. Confirm the feed-point plan separately.
The sheet lists 3000K / 4000K / 6500K / BLUE. State the required CCT and color tolerance, then approve a powered sample in the intended profile and diffuser. For repeat orders, agree how batch matching will be checked.
Use the model drawing to confirm the permitted bend direction, minimum radius, cutting unit, cable exit, end cap and mounting clips or channel. Test the tightest project curve without twisting the profile before approving production.
Record model neon light 8*16mm and check AC220V input and 9W/M power, 3000K / 4000K / 6500K / BLUE, 50M, Confirm for selected construction, color matching. Add the production-intent driver or rectifier, connector, profile and packaging. The signed specification and retained sample should control later batch inspection.
The quotation, specification sheet and approved sample should identify the same model, electrical rating, construction, reel length and packaging. Record measurable acceptance limits before production rather than relying on a family-level description.
